Product Details:
Payment & Shipping Terms:
|
| Standard Or Nonstandard: | Standard | Power: | Hydraulic |
|---|
| Operation: | Double acting |
|---|---|
| Standard: | ISO 15552;ISO 6431;NFE 49-003-1;VDMA 24 562 |
| Stroke length: | 200 mm |
| Port size: | G3/8 |
| Cylinder diameter: | 80 mm |
| Medium: | Compressed air |
|---|---|
| Port size: | G3/8 |
| Operation: | Double acting |
| Operating pressure: | 1 ... 16 bar |
| Operating temperature: | -20 ... 80 °C |
| Cylinder diameter: | 80 mm |
| Piston rod diameter: | 25 mm |
| Stroke length: | 200 mm |
| Standard: | ISO 15552;ISO 6431;NFE 49-003-1;VDMA 24 562 |
| Theoretical force: | 3016 N |
| Material - Elastomers: | Nitrile rubber;Polyurethane |
| Material - Piston head seals: | Polyurethane |
| Material - Piston rod: | Stainless steel (Martensitic) |
| Material - Seals: | Nitrile rubber;Polyurethane |
