Product Details:
Payment & Shipping Terms:
|
Specifications:
|
Application |
industry, machinery, mine,metallurgy, shipping, water conservancy, etc. |
|
Working Length |
50mm—16000mm |
|
Tube inside diameter |
40mm—1000mm |
|
Piston diameter |
12mm—410mm |
|
Working Pressure |
70 bar—700 bar |
|
Seal type |
PARKER (USA) or MERKEL (Germany) |
|
Material of liner |
copper (prolongs the life cycle of cylinder) |
Bore: 40 – 1000 mm (1 1/2 – 40 inch)
Rod: 12 – 500 mm (1/2 – 20 inch)
Rod should be hard chromed to minimum depth of 25 microns and polished to 0.15 um Ra
Plate: Cr, Ni or Ceramic
Stroke: Max 15 500 mm (610 inch)
Design Pressure: Max 700 bar (10150 PSI)
Weight: Max 60 tons
Valves: SUN (USA)
Seals: PARKER (USA), MERKEL (Germany) or NOK (Japan)
Bearing: LONGXI (China) or SKF
Painting: follow with customer requirement or 3-coat marine painting
Certificate: DNV, ABS, Lloyds, BV, GL, KR, NK, RINA, RS and CCS
Material: Carbon steel, Alloy steel, Stainless steel
Detail manufacturing drawings to be submitted to buyer for approval before manufacture is commenced.
