Product Details:
Payment & Shipping Terms:
|
| Structure: | Piston Pump | Usage: | Oil |
|---|---|---|---|
| Power: | Hydraulic | Standard Or Nonstandard: | Standard |
| Fuel: | Gasoline | Pressure: | High Pressure |
-- High performance rotary group with well-proven spherical control area offering the following advantages, self-centering.
-- Low periph-eral speed
-- High efficient.
-- Long service life robust rolling bearing.
-- Drive shaft will support radial loads.
-- Low noise level.
-- High duty roller bearing for intermettent high pressure operation.
-- For continuous duty hydrostatic are availabe.
-- Excellent starting characteristics.
-- High power density
-- Optional mounting position
Specification:
| Model | Nominal Pressure (MPa) | Nominal Displacement (cc/rev) | Theoretic Flow (LPM) | Max Drive Power (kW) | Max. Theoretic Torque (N.m) | ||
| 1000rpm | 1500rpm | ||||||
| 2.5 | CY14-1B | 31.5 | 2.5 |
2.5 |
3.75 | 1.43 | 17.5 |
| 10 | CY14-1B | 31.5 | 10 | 10 | 15 | 5.7 | 54.6 |
| 25 | CY14-1B | 31.5 | 25 | 25 | 37.5 | 14.1 | 134.9 |
| 40 | CY14-1B | 31.5 | 40 | 40 | 60 | 22.6 | 201.6 |
| 63 | CY14-1B | 31.5 | 63 | 63 | 94.5 | 35.6 | 339.9 |
| 80 | CY14-1B | 31.5 | 80 | 80 | 120 | 46.6 | 405.1 |
| 160 | CY14-1B | 31.5 | 160 | 160 | 240 | 92.2 | 880.3 |
| 250 | CY14-1B | 31.5 | 250 | 250 | 375 | 133.2 | 1272.4 |
| 400 | CY14-1B | 31.5 | 400 | 400 | 505 | 199.5 | 1905.2 |
